Latex Printing Solution for Leather

Latex Printing Solution for PU/PVC Leather

Project Background

Latex ink printing has always been a product of an imported American brand. Due to limitations in printing costs, printing effects and other reasons, it has always been a very niche product application in the inkjet industry. However, with the development of the industry in recent years, higher requirements have been put forward for digital inkjet printing. The characteristics of latex ink, such as water-based environmental protection and strong functionality, are important directions for the future development of the industry......

Leather Printng Show

Customer Pain Point

There is no way to print images directly on uncoated media with normal water-based inks, let alone the fastness. The biggest functional advantage of water-based latex inks is that they can print images on uncoated media and achieve extremely high fastness. Spend.

Leather Printing Solution Advantages

Use mesh belt platform to feed the printing material, adopts industrial grade high-power fans to guarantee smooth transmission.
The partitioned and adjustable powerful air suction function, can feed the printing material smoothly and falt, totally avoiding the deformation, wrinkle, sticking, scratching during printing.
Suit for different kinds of media, especially the materials with specific thickness, hardness and stretchability, all can be printed with this printer. This high value-added printing solution is more Eco-friendly,can greatly expand user’s business scope.
Imported linear guide rail;Germany imported wires; imported high-power AC servo motor; Carriage anti-collision device; Fully automatic ink supplying & alarming system.

Latex Printer Specification

Printing Specifications			Computer Configuration
Printhead	EPSON I32100-A1		Compputer	CPU: i5 internal storage > 8GB
Printhead No.	3-4		System	Win7 / Win 10
Output Precision	3601800dpi 7201080dpi 720*2400dpi		Interface	USB
Printing Speed	OP+W+Color	OP+W+Color+Color	Software	MainTop, PhotoPrint
Economy Mode	22m²/h	34m²/h	Power Source	AC-220V, 50Hz / 60Hz
Production Mode	16m²/h	25m²/h	Power	3KW
Quality Mode	13m²/h	20m²/h	Packaging Specifications
Ink Configration			Machine Dimension	3760 * 1130 * 1600mm (L * W * H)
Ink Type	Water-based eco-friendly latex ink		Net Weight	1000kg
Color	KCMY (LC/LM/R/B/OR/FM/FY for optional) + W + OP		Package Dimension	3800 * 1180 * 1650mm (L * W * H)
Ink Supply	Big capacity ink supplying system + ink shortage alarm + white ink circulation		Gross Weight	1100kg

Latex Printing Solution Value

Hongsam JETALL water-based latex ink is environmentally friendly. There is no odor either during the printing process or in the finished product. It effectively improves the environmental quality of the product and caters to market needs. It improves the production environment and reduces labor risks. There are no flammable consumables, which reduces production fire risks. . It has the advantages of adapting to the diversity of printing media and image durability, and is especially suitable for industries with extremely high environmental requirements such as decoration, wallpapers and murals. It is a functional ink that represents the future direction of inkjet printing.
